TDD 系列由除濕、干燥兩種功能一體，廣泛適用于各種塑膠原料，尤其是吸濕性較強的工程塑料，如：PA、PC、PBT、PET 等，蜂巢轉輪在理想的狀態下最低可達到 -40℃以下的露點。該系列產品采用 TD-H 系列蜂巢轉輪除濕機搭配下吹式全不銹鋼歐化保溫干燥料桶組合而成。
TDD series by dehumidification, drying two functions in one, widely used in all kinds of plastic raw materials, especially strong hygro?scopic engineering plastics, such as: PA, PC, PBT, PET, etc., honeycomb wheel in the ideal state can reach the lowest dew point below -40℃. This series of products is made of TD-H series honeycomb wheel dehumidifier combined with down-blown all stainless steel European thermal insulation drying drum
TDD 系列歐化除濕干燥組合一律配備蜂巢轉輪除濕機，造型為半開放式，整體造型美觀新穎；集除濕、干燥兩種功能為一體，并可選擇一對多的系統；保溫式干燥料桶采用特有下吹風管設計搭配旋風排氣裝置能提高干燥效率，并能防止熱能散失，確保濕度；該系列除濕系統采用雙冷卻器結構，確保更低回風溫度及露點；
機器占地小，移動方便，可任意更換機臺使用；
該機配備微電腦控制為標準，可選配 PLC 控制搭配 LCD 觸控式人機界面，操作集中方便，可控制整機自動運行；
可選配露點計，方便隨時監控露點；
可選配吸料盒與自動填料機，方便原料輸送；
改符合歐規安全回路型時，機型加注“CE”。
The TDD series Europeanized dehumidification and drying units are all equipped with honeycomb wheel ehumidifier, which is semi-open in shape and beautiful and novel in overall shape. Set dehumidification, drying two functions as one, and can choose one to many system;
The thermal insulation drying barrel adopts the unique downblowing air pipe design with cyclone exhaust device to improve the drying efficiency, and can prevent heat loss, to ensure the temperature;
This series of dehumidification system adopts double cooler structure to ensure lower return air temperature and dew point;
The machine covers an area of small, easy to move, more arbitrary change machine use;
The machine is equipped with microcomputer control as the standard, can choose PLC control with LCD touch man-machine interface, centralized oper?ation is convenient, can control the centralized operation of the whole machine;
Optional dew point meter, easy to monitor dew point at any time;
Optional suction box and automatic filler, convenient raw material transportation;
Add "CE" when changing to comply with European safety circuit type.
|
|
